Manually loaded steam boiler
ENERGY CONSERVATION AND ENVIRONMENTAL PROTECTION
TAdopt the latest national energy-saving and emission-reduction design requirements, evenly arrange horizontal water pipes, reduce exhaust temperature, and save energy and reduce emissions..
CLASSIC STRUCTURAL DESIGN
The classic furnace design has been on the market for decades and has been running stably for more than ten years.
HORIZONTAL WATER PIPE LAYOUT
The horizontal water pipes are evenly arranged in the furnace and staggered with each other, which can effectively cut the flue gas, block the fine particles in the smoke, and drop them to the grate for secondary full combustion, making full use of the heating surface and improving the thermal efficiency of the boiler.
MANUAL LOADING
It adopts manual loading and large furnace door design, which is convenient for feeding. It can use biomass fuel: such as wood blocks, wood strips and other large-volume fuels, and can also use coal* as fuel..
AUTOMATIC CONTROL
Automatically monitor water level and realize automatic water replenishment function..
SAFETY INTERLOCK PROTECTION
Equipped with multiple interlocking protections such as over-temperature*, over-pressure, water shortage, full water, leak detection*, flameout, etc. to ensure safe and reliable operation.
HEAT RECOVERY
The flue gas waste heat recovery device* is installed after the boiler to reduce the exhaust gas temperature and improve the thermal efficiency of the boiler; it also reduces fuel consumption and saves operating costs.
*：Optional configuration
| Model |
Rated Evaporatio Capacity (t/h) |
Rated Evaporation Pressure(Mpa) |
Thermal Efficiency(%) |
Consumption (Coal-fired kg/h) |
Consumption (Biomass fuel kg/h) |
| LSG0.1-0.7-AII(SCII) | 0.1 | 0.4/0.7 | ≥83% | 10-20 | 220-40 |
| LSG0.2-0.7-AII(SCII) | 0.2 |
0.4/0.7 |
≥83% | 20-30 | 40-60 |
| LSG0.3-0.7-AII(SCII) | 0.3 | 0.4/0.7 | ≥83% | 40-50 | 80-100 |
| LSG0.5-0.7-AII(SCII) | 0.5 | 0.4/0.7 | ≥83% | 60-70 | 120-140 |
| LSG0.7-0.7-AII(SCII) | 0.7 | 0.4/0.7 | ≥83% | 80-100 | 160-200 |
| LSG1-0.7-AII(SCII) | 1 | 0.4/0.7 | ≥83% | 100-120 | 200-250 |
FUEL OPTIONS INCLUDE: Coal-fired、Biomass Fuel AND MORE. The calorific value of coal is 4500kcal/kg, and that of Biomass Fuel is 3000kcal/kg
Note: Due to technical updates, we cannot display all the latest parameters here. If we make changes, we will not modify them here. We have more models for you to choose from. If your needs are not found here, please contact us.
