Steam generator, steam boiler, gas-fired steam generator, oil-fired steam generator.Oil and gas steam generator, not steam boiler.
ENERGY CONSERVATION AND ENVIRONMENTAL PROTECTION
In view of the characteristics of biomass fuel combustion, this boiler adopts secondary air and a larger furnace volume, which can promote the fuel to burn fully and effectively in the furnace, achieving the purpose of energy saving and environmental protection..
THREE-RETURN STRUCTURE
The furnace body has a true three-pass structure, and the flue gas circulates three times in the furnace. It is not a false three-pass design (two passes in the furnace + energy saver), and it is not a direct exhaust type! The flame burns in the combustion chamber with a slight positive pressure, the combustion heat load is low, and the emission of harmful substances such as nitrogen oxides and NOx is low; high reliability and low maintenance costs.
THREADED SMOKE PIPE
This boiler adopts threaded smoke pipe, which increases the heating area and has the characteristics of fast startup and ignition.
AUTOMATIC CONTROL
With the fully automatic control system, you only need to set the required pressure/temperature and other parameters to achieve fully automatic control: automatic start and stop of the burner, automatic water replenishment and other operations; reduce the labor intensity of boiler operators and reduce misoperation caused by human factors.
SAFETY INTERLOCK PROTECTION
Equipped with multiple interlocking protections such as over-temperature*, over-pressure, water shortage, full water, leak detection*, flameout, etc. to ensure safe and reliable operation.
HEAT RECOVERY
The flue gas waste heat recovery device* is installed after the boiler to reduce the exhaust gas temperature and improve the thermal efficiency of the boiler; it also reduces fuel consumption and saves operating costs.
*：Optional configuration
Warm reminder: This product is illegal under Chinese laws and regulations, please choose carefully.
| Model |
Rated Evaporatio Capacity (t/h) |
Rated Evaporation Pressure(Mpa) |
Thermal Efficiency(%) |
Consumption (Diesel kg/h) |
Consumption (Nature Gas Nm³/h) |
| LHS0.1-0.7-QY | 0.1 | 0.7 | ≥83% | 10-12 | 12-15 |
| LHS0.2-0.7-QY | 0.2 |
0.7 |
≥83% | 15-20 | 20-25 |
| LHS0.3-0.7-QY | 0.3 | 0.7 | ≥83% | 20-25 | 25-30 |
| LHS0.5-0.7-QY | 0.5 | 0.7 | ≥83% | 25-30 | 30-35 |
| LHS0.7-0.7-QY | 0.7 | 0.7 | ≥83% | 30-40 | 40-50 |
| LHS1-0.7-QY | 1 | 0.7 | ≥83% | 50-60 | 60-75 |
FUEL OPTIONS INCLUDE: LPG, LNG, CNG, LIGHT DIESEL, HEAVY OIL AND MORE.
Note: Due to technical updates, we cannot display all the latest parameters here. If we make changes, we will not modify them here. We have more models for you to choose from. If your needs are not found here, please contact us.
