Oil & Gas Hot Air Boiler (Mixed Air)
AUTOMATIC CONTROL
With the fully automatic control system, you only need to set the required pressure/temperature and other parameters to achieve fully automatic control: automatic start and stop of the burner, automatic water replenishment and other operations; reduce the labor intensity of boiler operators and reduce misoperation caused by human factors.
SAFETY INTERLOCK PROTECTION
Equipped with multiple interlocking protections such as over-temperature*, over-pressure, water shortage, full water, leak detection*, flameout, etc. to ensure safe and reliable operation.
*：Optional configuration
| MODEL | RATED HEATING CAPACITY(kw/h) | RATED HOT AIR TEMPERATURE(℃) | THERMAL EFFICIENCY(%) |
CONSUMPTION (DIESEL kg/h) |
CONSUMPTION (NATURAL GAS Nm3/h) |
| WRF-120Y(Q) | 120(10×104KCal) | ≥300 | ≥93 | 8-12 | 10-15 |
| WRF-240Y(Q) | 240(20×104Kcal) | ≥300 | ≥93 | 15-22 | 20-25 |
| WRF-350Y(Q) | 350(30×104KCal) | ≥300 | ≥93 | 25-30 | 30-35 |
| WRF-500Y(Q) | 500(40×104Kcal) | ≥300 | ≥93 | 35-42 | 40-50 |
| WRF-700Y(Q) | 700(60×104KCal) | ≥300 | ≥93 | 55-65 | 60-75 |
| WRF-1000Y(Q) | 1000(80×104Kcal) | ≥300 | ≥93 | 75-95 | 80-100 |
| WRF-1200Y(Q) | 1200(100×104KCal) | ≥300 | ≥93 | 95-115 | 100-120 |
| WRF-1400Y(Q) | 1400(120×104Kcal) | ≥300 | ≥93 | 115-145 | 120-150 |
| WRF-1800Y(Q) | 1800(150×104KCal) | ≥300 | ≥93 | 145-175 | 150-180 |
| WRF-2100Y(Q) | 2100(180×104Kcal) | ≥300 | ≥93 | 175-205 | 180-210 |
| WRF-2400Y(Q) | 2400(200×104KCal) | ≥300 | ≥93 | 215-235 | 220-240 |
| WRF-3000Y(Q) | 3000(250×104Kcal) | ≥300 | ≥93 | 275-305 | 280-310 |
| WRF-3500Y(Q) | 3500(300×104KCal) | ≥300 | ≥93 | 295-345 | 300-350 |
| WRF-4200Y(Q) | 4200(360×104Kcal) | ≥300 | ≥93 | 355-455 | 360-420 |
| WRF-4800Y(Q) | 4800(400×104KCal) | ≥300 | ≥93 | 395-455 | 400-460 |
| WRF-6000Y(Q) | 6000(500×104Kcal) | ≥300 | ≥93 | 495-595 | 500-600 |
| WRF-7000Y(Q) | 7000(600×104KCal) | ≥300 | ≥93 | 595-715 | 600-720 |
FUEL OPTIONS INCLUDE: LPG, LNG, CNG, LIGHT DIESEL, HEAVY OIL AND MORE.
Note: Due to technical updates, we cannot display all the latest parameters here. If we make changes, we will not modify them here. We have more models for you to choose from. If your needs are not found here, please contact us.
