This is a vertical steam boiler, which is supervised by a third-party regulatory agency and must comply with China‘s "Regulations on Boiler Safety Technical Supervision". It only takes 3-5 minutes to generate steam, which is very fast.
ULTRA-LOW NITROGEN TECHNOLOGY
The core low-nitrogen furnace technology + fully automatic low-nitrogen burner* is adopted to achieve boiler tail gas nitrogen oxide emissions ≤30mg/m³, which meets national environmental protection requirements.
3-5 MINUTES TO GENERATE STEAM
It only takes 3-5 minutes from the time cold water enters the boiler to the time steam is generated, which is 10 times faster than other types of boilers..
W-TYPE FLUE GAS FLOW
The special W-shaped flue gas flow maximizes the retention time of flue gas in the furnace, fully performs heat exchange, effectively improves boiler thermal efficiency, and reduces exhaust temperature..
AUTOMATIC CONTROL
With the fully automatic control system, you only need to set the required pressure/temperature and other parameters to achieve fully automatic control: automatic start and stop of the burner, automatic water replenishment and other operations; reduce the labor intensity of boiler operators and reduce misoperation caused by human factors.
SAFETY INTERLOCK PROTECTION
Equipped with multiple interlocking protections such as over-temperature*, over-pressure, water shortage, full water, leak detection*, flameout, etc. to ensure safe and reliable operation.
HEAT RECOVERY
The flue gas waste heat recovery device* is installed after the boiler to reduce the exhaust gas temperature and improve the thermal efficiency of the boiler; it also reduces fuel consumption and saves operating costs.
*：Optional configuration
| Model |
Rated Evaporatio Capacity (t/h) |
Rated Evaporation Pressure(Mpa) |
Thermal Efficiency(%) |
Consumption (diesel kg/h) |
Consumption (Natural Gas Nm³/h) |
| LSS0.5-1.0-Y(Q) | 0.5 | 1.0/1.25/1.6 | ≥93% | 30 | 35 |
| LSS1-1.0-Y(Q) | 1 | 1.25/1.6/2.0/2.5/3.8 | ≥93% | 50-60 | 60-75 |
| LSS2-1.25-Y(Q) | 2 |
1.25/1.6/2.0/2.5/3.8 |
≥93% | 100-120 | 120-150 |
| LSS3-1.25-Y(Q) | 3 | 1.25/1.6/2.0/2.5/3.8 | ≥93% | 150-180 | 180-225 |
FUEL OPTIONS INCLUDE: LPG, LNG, CNG, LIGHT DIESEL, HEAVY OIL AND MORE.
Note: Due to technical updates, we cannot display all the latest parameters here. If we make changes, we will not modify them here. We have more models for you to choose from. If your needs are not found here, please contact us.
